S2H1000CB
10MP 1/2.3" USB2.0 Binocular Camera Module
Cost-effective
one-to-oneservice
Requirement customization
provide home delivery service
24-hour after-sales service
WhatsApp
Product
Parameter
Download
| Product Features CHARACTERISTIC |
|
Model | S2H1000CB-1 |
Resolution | 10MP |
Type | 10MP 1/2.3" USB2.0 Binocular Camera Module |
Sensor Type | CMOS |
Sensor | MT9J003 |
Mono/Color | Color |
Shutter | Rolling Shutter |
Resolution(HxV) | 3664×2748 |
Frame Rate | |
Sensor size | 1/2.3" |
Pixel size | 1.67µm x 1.67µm |
SNR | 34dB |
Gain | 8dB |
Dynamic Range | 65.2dB |
Exposure Time | 0.1610-1770ms |
Sensitivity | 0.31mV/lux-s |
Pixel Bit depth | 8/10bit |
Pixel Format | Mono 8/10 Bayer 8/10 |
Binning | Supports 1×1，1×2，2×1，2×2 |
Image buffer | 32M Bytes |
User parameter area | 4K Bytes |
Capture mode | Continuous/Soft trigger/Hard trigger |
Data Interface | USB2.0 @ 480Mbps |
transmission distance | 5m |
Digital I/O | I/O: One opto-isolated input, and two opto-isolated output |
Power supply | 5VDC,USB2.0 power supply |
Power consumption | ＜3.0 W@5 VDC |
Dimension | 115mmx27mmx24.6mm（Including lens and lens mount） |
Lens mount | M12 |
Weight (typical) | 30g（Including lens and lens mount） |
Temperature | Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: -30 °C to 70 °C (-22 °F to 158 °F) |
Humidity | 20% to 80% RH, without condensation |
Driver | DirectShow、Twain、Halcon、OCX |
Software support | Halcon、OpenCV、LabView、Matlab |
Development languages | C/C++、VB6、VB.net、Delphi6、C#、QT、C++Builder、LabView、Python |
Operating system | Windows、Linux、Android、MacOS |
Compatibility | Directshow、Twain |
